Spindle machine data
To operate the spindle in the previous example in JOG mode after commissioning the drive,
enter the new values for the following machine data:
Spindle machine data Default setting New value
MD32000 $MA_MAX_AX_VELO 10000 3000
MD32010 $MA_JOG_VELO_RAPID 10000 100
MD32020 $MA_JOG_VELO 2000 50
MD35100 $MA_SPIND_VELO_LIMIT 10000 3000
MD35110[0] $MA_GEAR_STEP_MAX_VELO[0] 500 3000
MD35110[1] $MA_GEAR_STEP_MAX_VELO[1] 500 3000
MD35130[0] $MA_GEAR_STEP_MAX_VELO_LIMIT[0] 500 3150
MD35130[1] $MA_GEAR_STEP_MAX_VELO_LIMIT[1] 500 3150
MD36200[0] $MA_AX_VELO_LIMIT[0] 11500 3300
MD36200[1] $MA_AX_VELO_LIMIT[1] 11500 3300
Maximum speed drive parameter
After a DDS switchover,
e.g. DDS0 → DDS1, the spindle can only be traversed with the speed
from p1082[0]. If a value less than that in p1082[1 ... n] is entered in p1082[0], the spindle
speed is limited to the value in p1082[0].
Note
The maximum speed must be entered in parameter p1082[0]:
● If the parameter is assigned a greater value than in the other parameters, the spindle can
be traversed with the maximum speed.
● If parameter p1082[0] is subsequently changed to a lower value and then a "Reset (po)"
performed, then the spindle only traverses with the lower value from p1082[0]. All other
values are ignored.
Diagnostics displays
Further information on the
status of axes and spindle is available in the "Diagnostics" operating
area with the menu forward key:
● The "Axis diagnostics" softkey opens the "Service Overview" dialog.
● The "Service axis" softkey opens the "Service Axis/Spindle" dialog.
Commissioning the drive
5.2 Assigning axes
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 133
