DB9903 Initial data table [r16]
DBW14 Reserved 2
... ...
DBW248 Interval 32 [h]
DBW250 Time of first warning 32 [h]
DBW252 Number of warnings to be output 32
DBW254 Reserved 32
Interval: Number of hours after which the maintenance must be performed. When this time expires, the
warning or alarm bit belonging to the task is set for the last time.
Time of the first
warning: Number of hours after which the first warning is output. This time must be greater
than or equal to the interval.
Number of warnings to be output: Number of n warnings to be output before the alarm. The alarm bit is
therefore set maximum (n+1)-times, i.e n-times as warning and 1-time as alarm.
Reserved: Reserved for expansions.
Example:
Interval = 100
Time of the 1st warning = 80
Number of warnings to be output = 2
After the task is started, the warning/alarm bit is output for the first time after 80 hours, a second
time after a further 10 hours (i.e. after a total of 90 hours), and the warning/alarm bit is set for
the last time after 100 hours.
DB9904: Actual data
DB9904 Actual data table [r16]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBW0 Remaining time 1 [h]
DBW2 Number of warnings output 1
DBW4 Reserved_1 1
DBW6 Reserved_2 1
DBW8 Remaining time 2 [h]
DBW10 Number of warnings output 2
DBW12 Reserved_1 2
DBW14 Reserved_2 2
... ...
DBW248 Remaining time 32 [h]
DBW250 Number of warnings output 32
Service Planner
7.1 Interfaces in the PLC user program
CNC commissioning
226 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
