MD52270: $MCS_TM_FUNCTION_MASK
Tool management function mask
MD52270: $MCS_TM_FUNCTION_MASK
Bit 0: Creating a tool at the magazine location is not permitted.
Tools can only be created outside of the magazine.
Bit 1: Load/unload lock, if the machine is not in the reset state.
Tools can only be loaded/unloaded when the relevant channel is in the reset state.
Bit 2: Load/unload lock for EMERGENCY STOP.
Tools can only be loaded/unloaded when EMERGENCY STOP is not active.
Bit 3: Tool in/out of spindle load/unload locked.
Tools cannot be loaded to or unloaded from the spindle.
Bit 4: Loading is performed directly into the spindle.
Tools are only loaded directly into the spindle.
Bit 5: Reserved
Bit 6: Reserved
Bit 7: Create tool using the T number.
The T number of the tool must be entered when creating a tool.
Bit 8: Hide tool relocation.
The "Relocate tool" function is hidden in the user interface.
Bit 9: Hide magazine positioning.
The "Position magazine" function is hidden in the user interface.
Bit 10: Reactivate tool with magazine positioning.
Before reactivating, the tool is positioned at the loading point.
Bit 11: Reactivate tool in all monitoring types.
When reactivating a tool, all the monitoring types for this tool enabled in the NC are reac‐
tivated. I.e. also the monitoring types that are not set for the relevant tool, but are only in
the background.
Bit 12: Hide reactivating tool.
The "Reactivate tool" function is hidden in the user interface.
Tool management
9.2 Machine data for the tool management
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 261
