● Multitool: Tool distance
Value for the distance coding: Tool location number in the multitool, or angle or distance
of the tool within the multitool
● Multitool: Number
T number of the multitool
● Multitool: Location number
Consecutively numbered location in the multitool
● Multitool: Spindle number / tool holder number
Spindle number / tool holder number associated with the multitool
Acknowledgments: Interface description
DB4000...40xx
Signals to tool management [r/w]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBBy000 Acknowl‐
edgment
step 7
Acknowl‐
edgment
step 6
Acknowl‐
edgment
step 5
Acknowl‐
edgment
step 4
Acknowl‐
edgment
step 3
Acknowledg‐
ment step 2
Acknowl‐
edgment
step 1
Total ac‐
knowledg‐
ment
DBBy001 Acknowl‐
edgment
step 15
Acknowl‐
edgment
step 14
Acknowl‐
edgment
step 13
Acknowl‐
edgment
step 12
Acknowl‐
edgment
step 11
Acknowledg‐
ment step 10
Acknowl‐
edgment
step 9
Acknowl‐
edgment
step 8
DBBy002 Acknowl‐
edgment
step 23
Acknowl‐
edgment
step 22
Acknowl‐
edgment
step 21
Acknowl‐
edgment
step 20
Acknowl‐
edgment
step 19
Acknowledg‐
ment step 18
Acknowl‐
edgment
step 17
Acknowl‐
edgment
step 16
DBBy003 Reserved Acknowl‐
edgment
step 30
Acknowl‐
edgment
step 29
Acknowl‐
edgment
step 28
Acknowl‐
edgment
step 27
Acknowledg‐
ment step 26
Acknowl‐
edgment
step 25
Acknowl‐
edgment
step 24
DBWy004 Multitool: Location number (INT)
DBBy006 Reserved
DBBy007 Reserved
DBBy008 Reserved
DBBy009 Job ac‐
knowledg‐
ment
Resetting
the ac‐
knowledg‐
ment error
DBBy010 Reserved
y [= 0 or 1]: TO unit 1 or TO unit 2
xx: Load location
Tool management
9.3 NC ↔ PLC user interface
