● Multitool: Number of locations
Number of tool locations available in the multitool
● Multitool: Tool distance
Value for the distance coding: Tool location number in the multitool, or angle or distance
of the tool within the multitool
● Multitool: Number (source) / multitool: Location number (source) of the new tool
Magazine number
/ location number from where the new multitool comes (mostly a location
in a real magazine).
● Multitool: Number (target) / multitool: Location number (target) of the old tool
Magazine number / location number to where the old multitool is to be transported (mostly
a location in a real magazine).
● Location type: Location type of the new tool
● Size left: Space required for the multitool in the magazine at the left
● Size right: Space required for the multitool in the magazine at the right
● Size top: Space required for the multitool in the magazine at the top
● Size bottom: Space required for the multitool in the magazine at the top
● Tool status
● T number of the tool
● Spindle number / tool holder number
● Multitool: Original magazine number
● Multitool: Original location number
Acknowledgments: Interface description
DB4200 ... 42xx Signals to tool management [r/w]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBBy000 Acknowl‐
edgment
step 7
Acknowl‐
edgment
step 6
Acknowl‐
edgment
step 5
Acknowl‐
edgment
step 4
Acknowl‐
edgment
step 3
Acknowl‐
edgment
step 2
Acknowl‐
edgment
step 1
Total ac‐
knowledg‐
ment
DBBy001 Acknowl‐
edgment
step 15
Acknowl‐
edgment
step 14
Acknowl‐
edgment
step 13
Acknowl‐
edgment
step 12
Acknowl‐
edgment
step 11
Acknowl‐
edgment
step 10
Acknowl‐
edgment
step 9
Acknowl‐
edgment
step 8
DBBy002 Acknowl‐
edgment
step 23
Acknowl‐
edgment
step 22
Acknowl‐
edgment
step 21
Acknowl‐
edgment
step 20
Acknowl‐
edgment
step 19
Acknowl‐
edgment
step 18
Acknowl‐
edgment
step 17
Acknowl‐
edgment
step 16
DBBy003 Reserved Acknowl‐
edgment
step 30
Acknowl‐
edgment
step 29
Acknowl‐
edgment
step 28
Acknowl‐
edgment
step 27
Acknowl‐
edgment
step 26
Acknowl‐
edgment
step 25
Acknowl‐
edgment
step 24
DBWy004 Multitool: Location number (INT)
DBBy006 Reserved
DBBy007 Reserved
DBBy008 Reserved
Tool management
9.3 NC ↔ PLC user interface
CNC commissioning
276 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
