DB9900 Constant transfer-step table [r]
…
DBW504 Transfer step 64 Source magazine number (INT)
DBW506 Transfer step 64 Source location number (INT)
DBW508 Transfer step 64 Target magazine number (INT)
DBW510 Transfer step 64 Target location number (INT)
DB9901 Variable transfer-step table [rw]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBW0 Transfer step 101 Source magazine number (INT)
DBW2 Transfer step 101 Source location number (INT)
DBW4 Transfer step 101 Target magazine number (INT)
DBW6 Transfer step 101 Target location number (INT)
DBB 8 Transfer step 102 Source magazine number (INT)
DBW10 Transfer step 102 Source location number (INT)
DBW12 Transfer step 102 Target magazine number (INT)
DBW14 Transfer step 102 Target location number (INT)
…
DBW504 Transfer step 164 Source magazine number (INT)
DBW506 Transfer step 164 Source location number (INT)
DBW508 Transfer step 164 Target magazine number (INT)
DBW510 Transfer step 164 Target location number (INT)
Acknowledgment step table
Each entry indexes two transfer steps (for the new and old tool) and gives the corresponding
status reached. The acknowledgment-step table in DB9902 is used jointly for
acknowledgments on the interface
of the loading point and on the interface of the tool holder.
DB9902 Acknowledgment-step table [r]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBB0 Acknowledgment step 1 Transfer step for new tool (BYTE)
DBB1 Acknowledgment step 1 Transfer step for old tool (BYTE)
DBB2 Acknowledgment step 1 Acknowledgment status (BYTE)
DBB3 Acknowledgment step 1 reserved
DBB4 Acknowledgment step 2 Transfer step for new tool (BYTE)
DBB5 Acknowledgment step 2 Transfer step for old tool (BYTE)
DBB6 Acknowledgment step 2 Acknowledgment status (BYTE)
DBB7 Acknowledgment step 2 reserved
…
DBB116 Acknowledgment step 30 Transfer step for new tool (BYTE)
DBB117 Acknowledgment step 30 Transfer step for old tool (BYTE)
Tool management
9.3 NC ↔ PLC user interface
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 281
