Siemens SINUMERIK 828D Commissioning Manual

Variable $TC_MPP2 with index 7: Location type
Parameter assignment:
Read variable from
the NC
Address Signal Valid values
Job DB1200.DBX0.0 Start 0/1
DB1200.DBX0.1 Write variable 0
DB1200.DBB1 Number of variables 1 … 8
Parameter DB120x.DBW1000 Variables index 7
DB120x.DBW1002 Location number 1 … 31999
DB120x.DBW1004 Magazine number 1 … 9999
Result DB1200.DBX2000.0 Job completed 0/1
DB1200.DBX2000.1 Error in job 0/1
DB120x.DBX3000.0 Variable is valid 0/1
DB120x.DBB3001 Access result 0/3/5/10
DB120x.DBW3004 Data from NC variable n
Legend:
n > 0: Location type for virtual location
n = 0: "match all" (buffer)
n = 9999: undefined (no virtual location)
Variable $TC_MPP4 with index 8: Location state
Parameter assignment:
Read variable from
the NC
Address Signal Valid values
Job DB1200.DBX0.0 Start 0/1
DB1200.DBX0.1 Write variable 0
DB1200.DBB1 Number of variables 1 … 8
Parameter DB120x.DBW1000 Variables index 8
DB120x.DBW1002 Location number 1 … 31999
DB120x.DBW1004 Magazine number 1 … 9999
Tool management
9.4 PLC Program Blocks
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 295

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
