N880 $TC_MPP4[9999,PLACE]=2 ; Location status
N890 $TC_MPP5[9999,PLACE]=PLACE ; Location type index
N900 endfor
N910 STOPRE
;
;
N920; Offsets (clearances) ; Clearances to magazine
;
; Buffer
N930 for PLACE=1 to NUM_BUFFER
N940 $TC_MDP2[1,PLACE]=0
N950 endfor
N960 STOPRE
;
;Loading points
N970 for PLACE=1 to NUM_LOAD
N980 stopre
N990 $TC_MDP1[1,PLACE]=0
N1000 endfor
N1010 M30 ; End
Tool management
9.7 Application example for turning machine
CNC commissioning
308 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
