Components Data
NC data
● Compile cycles
● Standard and user cycles
● Definitions and macros
● Machine data
●
Setting data
● Option data
● Global (GUD) and local (LUD) user data
● Tool and magazine data
● Protection zone data
● R parameters
● Work offsets
● Compensation data
● Part programs
● Subprograms
● Workpieces
PLC data
● Main program (MAIN)
● Data blocks (DBs)
● User program
Drive data Binary format or ASCII format
HMI data
● Texts: PLC alarm texts, cycle alarm texts, part program message texts
from the machine manufacturer
●
Templates: Individual templates, workpiece templates
● Applications: Software applications, for example of the machine
manufacturer
● Configurations
●
Configuration: Configurations, incl. display machine data
● Help: Online help files
● Version data
● Reports: For example, action log, screenshots
● Program lists
● Dictionaries: For simplified Chinese and traditional Chinese (IME)
● Data backups: Channel data, axis data, etc. in ASCII format
● Programs on a local drive: Programs that are in the user memory area of
the CompactFlash card.
Easy Archive
10.2 Which data is backed up in the archive?
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 335
