SD43200 $SA_SPIND_S Speed for spindle start using NC/PLC
interface signal; value outputs using
the operating software
SD43202 $SA_SPIND_CONSTCUT_S Cutting speed for spindle start using
NC/PLC interface signal; value
outputs
using the operating software
SD43206 $SA_SPIND_SPEED_TYPE Spindle speed pipe for spindle start us‐
ing NC/PLC interface signal;
value out‐
puts using the operating software
Additional parameter assignments
We recommend the following additional parameter assignments:
Handwheel
MD11346 $MN_HANDWH_TRUE_DISTANCE = 3 Handwheel path or velocity specifica‐
tion
MD11602 $MN_ASUP_START_MASK bit 0, 3 =1 Ignore stop conditions for ASUB
MD20150 $MC_G_CODE_RESET_VALUE [7] = 2 Delete position of the G groups; run-up
G54 active
MD20624 $MC_HANDWH_CHAN_STOP_COND = 0xFFFF Definition of the behavior of traveling
with handwheel, channel-specific
MD32084 HANDWH_STOP_COND = 0x7FF Behavior, handwheel travel
MD52212 FUNCTION_MASK_TECH Bit 9 = 1 Function screen form across technolo‐
gies; work offset via softkey
Note
If,
in
machine
data
MD52212 FUNCTION_MASK_TECH bit 9 is set, the "WO selection" softkey
is displayed in the "Work Offset – G54 … G599" window.
Working area limits
MD28600 $MC_MM_NUM_WORKAREA_CS_GROUPS > 0 Number of coordinate system-specific
working area limits
MD20150 $MC_GCODE_RESET_VALUES[59] = 2 Delete position of the G groups; acti‐
vate working area limits of the group
Note
If $MC_GCODE_RESET_VALUES[59] = 2 is set in the MD20150 machine data, the "Limit
stops" softkey is displayed in the "Manual Machine" window. This requires that
$MC_MM_NUM_WORKAREA_CS_GROUPS also has the value 1 for MD28600.
Customizing the "Machine" operating area
5.8 Manual machine
SINUMERIK Operate
60 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
