Requirement
● For multi-channel machine, the following data must be the same for all channels:
– Measurement unit
– Zero offset (e.g. G54)
–
Z value of the zero offset (optional)
– Blank
– Speed limitation
● Further, the following JobShop-specific data must be the same for all channels:
– Retraction plane (one each for the main and counterspindle)
– Tailstock (one each for the main and counterspindle)
– Tool change point (one each for the main and counterspindle)
– Safety clearance
– Climbing and conventional
Creating a multi-channel program
For multi-channel machining, you require a job list with the following data:
● Program names
● Program type
● G code
● ShopTurn program
● Channel assignment
Software option
You require the "ShopMill/ShopTurn" option to generate and edit ShopTurn/
ShopMill programs.
After you have created a job list, in the "multi-channel data" parameter screen, you can combine
the data from the G code and JobShop, which is then saved as cycle call in the job list. The
"multi-channel data" parameter screen
is displayed as soon as at least one ShopTurn program
is contained in a job list.
Only programming G code programs
If the job list only contains G code programs, then you can deactivate the "multi-channel data"
function. To do this, set the following machine data:
MD51228 $MNS_FUNCTION_MASK_TECH Cross-technology function screen
Bit 0 G code programming without multi-channel data
= 1 Multi-channel data is not listed for job lists that only contain G code programs. The "multi-
channel data" softkey is not displayed.
Customizing the "Machine" operating area
5.9 Multi-channel support
