= 2 Auxiliary spindle (driven tool)
= 3 Main spindle (turning)
= 4 C axis of the main spindle (turning)
= 5 Counterspindle (turning)
= 6 C axis of the counterspindle (turning)
= 7 Linear axis of the counterspindle (turning)
= 8 Tailstock (turning)
= 9 Back rest (turning)
Enter the direction of rotation for the rotary axes that are not configured in a toolholder or a 5-
axis transformation via the following channel-specific machine data.
MD52207 $MCS_AXIS_USAGE_ATTRIB[n] Attributes of the axes
[n] channel axis number
Bit 0 Rotation around 1st geometry axis (for rotary axes)
Bit 1 Rotation around 2nd geometry axis (for rotary axes)
Bit 2 Rotation around 3rd geometry axis (for rotary axes)
Bit 3 Reversal of direction of rotation (for rotary axes)
The MD52290 $MCS_SIM_DISPLAY_CONFIG machine data acts only on the OP019. It has
no significance for SINUMERIK 828D.
MD52290 $MCS_SIM_DISPLAY_CONFIG Position of the status display of the channel in the
simulation.
Bit 0 Upper left-hand corner
Bit 1 Upper right-hand corner
Bit 2 Lower left-hand corner
Bit 3 Lower right-hand corner
In the channel-specific machine data, for at least one geometry axis per channel, enter a value
other than 0.0, e.g.
0.001. If the value is 0.0, the system assumes that this parameter has still
not been set.
MD53230 $MCS_SIM_START_POSITION Axis position when starting the simulation
Simulation is only possible if a value not equal to 0 has been set for at least one geometry axis.
Deactivating simulation
The following machine data must be set to deactivate the simulation:
MD51226 $MNS_FUNCTION_MASK_SIM Simulation function screen
Bit 1 = 1 Deactivate simulation
Bit 10 = 1 Hide zero point symbol
Simulation and simultaneous recording
6.2 Setting the technology for simulation
SINUMERIK Operate
68 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
