Note
Cylindrical and surface grinding are not supported as a technology extension by SINUMERIK
Operate.
References: grinding
For further information about the grinding technology, please refer to:
● Chapter "grinding (Page 133)"
●
Operating Manual, Grinding
● Programming Manual, Production Planning; Chapter "Programming cycles externally":
– CYCLE495 - form-truing
– CYCLE4071 - CYCLE4074: Longitudinal grinding cycles
– CYCLE4075 - CYCLE4079: Surface grinding cycles
● Function Manual, Extended Functions; Chapter "Compensations (K3)" > "Interpolatory
compensation" > "Cylinder error compensation"
Setting the coordinate system
MD52000 $MCS_DISP_COORDINATE_SYSTEM Position of the coordinate system
= 0 Default setting
With this machine data you adapt the position of the coordinate system of the user interface to the
coordinate system of the machine. In the user interface, all help screens, sequence graphics, simula‐
tions, and input fields with circle direction indication change automatically according to the selected
position.
The following settings can be selected for the coordinate system:
Configuring cycles
7.1 Activating turning/milling/drilling/grinding technologies
SINUMERIK Operate
76 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
