MD52216 $MCS_FUNCTION_MASK_DRILL Drilling function screen form
Bit 3 Constant cutting speed referred to the diameter of the centering
= 0 Constant cutting speed referred to the diameter of the tool
= 1 Constant cutting speed referred to the diameter of the centering
MD52218 $MCS_FUNCTION_MASK_TURN Turning function screen
Bit 2 Enable tailstock
Bit 5 Enable spindle control of the tool spindle via user interface
Bit 6 Enable Balance Cutting for two-channel stock removal
MD52229 $MCS_ENABLE_QUICK_M_CODES Enable fast M functions
Bit 0 Coolant OFF
Bit 1 Coolant 1 ON
Bit 2 Coolant 2 ON
Bit 3 Coolants 1 and 2 ON
MD52230 $MCS_M_CODE_ALL_COOLANTS_OFF M code for all coolants OFF
= 9 This machine data is used to define the M function for switching off the coolant; which is
output when the tool is changed.
MD52231 $MCS_M_CODE_COOLANT_1_ON M code for coolant 1ON
= 8 This machine data is used to define the M function for coolant 1, which is output when the
tool is changed.
MD52232 $MCS_M_CODE_COOLANT_2_ON M code for coolant 2ON
= 7 This machine data is used to define the M function for coolant 2, which is output when the
tool is changed.
MD52233 $MCS_M_CODE_COOLANT_1_AND_2_ON M code for both coolants ON
= -1 This machine data is used to define the M function for coolant 1 and 2, which is output when
the tool is changed.
SD55505 $SCS_TURN_ROUGH_O_RELEASE_DIST Retraction distance for stock remov‐
al during external machining
= 1 Specifies the distance, by which the tool is retracted from the contour when removing stock
from an outer corner. This does not apply to stock removal at a contour (default value).
= -1 The distance is internally defined.
Configuring cycles
7.5 Turning
SINUMERIK Operate
110 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
