Single-channel turning machine with X1 and Z1 axis, main spindle and tool spindle, servo revolver
(system 828D-TE42)
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Channel axis name in the channel
[0] = X1 Channel axis X1
[1] = Z1 Channel axis Z1
[2] = C1 Main spindle C1
[3] = SP1 Tool spindle SP1
[4] = Q1 Turn tool turret
Single-channel turning machine with X1, Z1, and Y1 axis, main spindle and tool spindle, servo turret
(system 828D-TE62)
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Channel axis name in the channel
[0] = X1 Channel axis X1
[1] = Z1 Channel axis Z1
[2] = C1 Main spindle C1
[3] = SP1 Tool spindle SP1
[4] = Y1 Channel axis Y1
[5] = Q1 Turn tool turret
Single-channel turning machine with X1, Z1, and Y1 axis, main spindle, counterspindle, and tool spindle,
counterspindle axis, servo turret (system 828D-TE821)
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Channel axis name in the channel
[0] = X1 Channel axis X1
[1] = Z1 Channel axis Z1
[2] = C1 Main spindle C1
[3] = SP1 Tool spindle SP1
[4] = Y1 Channel axis Y1
[5] = Q1 Turn tool turret
[6] = Z2 Counterspindle axis Z2
[7] = C2 Counterspindle C2
Two-channel turning machine with X1, Z1, and Y1 axis, main spindle and tool spindle, counterspindle
axis Z3, X2 and Z2 axis, counterspindle and tool spindle (system 828D-TE822)
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Channel axis name in channel 1
[0] = X1 Channel axis X1
[1] = Y1 Channel axis Y1
[2] = Z1 Channel axis Z1
[3] = C1 Main spindle C1
[4] = SP1 Tool spindle SP1
[5] = Z3 Counterspindle axis Z3
Configuring cycles
7.5 Turning
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 119
