[1] = 3 Rotary axis C1
[2] = 2 Parallel to the rotary axis Z1
MD24120 $MC_TRAFO_GEOAX_ASSIGN_TAB_1[ ] Assignment of the geometry axes to chan‐
nel axes for transformation 1.
[0] = 1 1st channel axis X1
[1] = 3 2nd channel axis Y1
[2] = 2 3rd channel axis Z1
MD24900 $MC_TRANSMIT_ROT_AX_OFFSET_1
= 0 Offset of the rotary axis for the 1st TRANSMIT transformation.
MD24905 $MC_TRANSMIT_ROT_AX_FRAME_1
= 2 Axial offset of the rotary axis is taken into account during TRANSMIT 1.
MD24910 $MC_TRANSMIT_ROT_SIGN_IS_PLUS_1
= 0 Sign of the rotary axis for the 1st TRANSMIT transformation.
MD24911 $MC_TRANSMIT_POLE_SIDE_FIX_1
= 1 Limitation of working range in front of/behind the pole, 1st TRANSMIT.
MD24920 $MC_TRANSMIT_BASE_TOOL_1[ ] Vector of the base tool for the 1st TRANS‐
MIT transformation.
[0] = 0
[1] = 0
[2] = 0
Face machining under ShopTurn
If you wish to use the face machining function under ShopTurn, set the following additional
channel-specific configuration machine data:
MD52214 $MCS_FUNCTION_MASK_MILL ShopTurn function screen
Bit 3 Enable "internal / rear" machining in ShopTurn screens that define the machining plane themselves.
Bit 4 If you have implemented the "Clamp/release spindle" function using the machine manufacturer cycle
CUST_TECHCYC.SPF, then using this machine data, you can activate the "Clamp/release spindle" param‐
eter in the drilling and milling masks.
= 0 The "Clamp/release spindle" parameter is not displayed in the drilling and milling masks. ShopTurn auto‐
matically clamps the spindle if it makes sense for the particular machining operation.
= 1 The "Clamp/release spindle" parameter is displayed in the drilling and milling screens. The operator decides
for which machining operation the spindle should be clamped.
Configuring cycles
7.5 Turning
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 127
