You can use the CUST_MEACYC.SPF to program and execute sequences that are necessary
before and/or after a measurement (e.g. activating/deactivating a probe).
Note
Copy the CUST_MEACYC cycle from the NC data/Cycles/Standard cycles directory to the NC
data/Cycles/User cycles directory before making any changes. Changes for CUST_MEACYC
only take effect in this directory.
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
174 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
