MD52750 $MCS_J_MEA_FIXPOINT Z value for measurement with respect to
a fixed point
[0] Position in the 1st axis
[1] Position in the 2nd axis
MD52751 $MCS_J_MEA_MAGN_GLAS_POS Zoom-in position for tool measurement
[0] Position in the 1st axis
[1] Position in the 2nd axis
Checking and setting the general machine data
MD11450 $MN_SEARCH_RUN_MODE Block search parameter settings
Bit 1 = 1 Automatic ASUP start after output of action sets. Alarm 10208 is not output until the ASUP
is ended (see also MD11620 $MN_PROG_EVENT_NAME).
MD11604 $MN_ASUP_START_PRIO_LEVEL Priorities from which ASUP_START_MASK is
effective.
= 1 - 64 Priorities for ASUP_START_MASK.
Setting channel-specific machine data
MD20050 $MC_AXCONF_GEOAX_ASIGN_TAB[ ] Assignment, geometry axis to channel axis.
[0] For measuring in JOG mode, all of the geometry axes must be available. Preferably XYZ.
[1]
[2]
MD20110 $MC_RESET_MODE_MASK Defines the basic control settings after reset /
TP end,
= 4045H Minimum value
Bit 0 = 1 Basic control setting after power on and reset.
Bit 2 = 1
Bit 6 = 1
Bit 14 = 1
MD20112 $MC_START_MODE_MASK Definition of the basic control setting after part
program start.
= 400H Minimum value
Bit 6 = 0 Definition of the basic control setting after NC start.
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 177
