Note
Measuring feedrate for workpiece measuring
All measuring cycles use the value saved in SD54611 as the measuring feedrate value
following calibration of the workpiece probe. A different measuring feedrate can be assigned
for each calibration field [n].
When calibrating the probe, either the measuring feedrate from SD55630
$SCS_MEA_FEED_MEASURE is used, or the measuring feedrate can be overwritten in the
input screen when calibrating. To do this, SD54760 $SNS_MEA_FUNCTION_MASK_PIECE
bit 4 must be set to 1.
MD52207 $MCS_AXIS_USAGE_ATTRIB[n] Attributes of the axes
[n] channel axis number
Bit 6 Request rotary axis as correction target for measuring.
= 0 Default value
=1 Rotary axis is displayed as correction target in the "Measuring in JOG" window.
MD51751 $MNS_J_MEA_M_DIST_MANUELL Measuring path in mm, before and after the
measuring point.
= 10 Default value
MD51757 $MNS_J_MEA_COLL_MONIT_FEED Position feedrate in mm/min, in the working
plane for active collision monitoring.
= 1000 Default value
MD51758 $MNS_J_MEA_COLL_MONIT_POS_FEED Position feedrate in mm/min, in the infeed
axis for active collision monitoring.
= 1000 Default value
MD51770 $MNS_J_MEA_CAL_RING_DIAM[n] Pre-assignment of the calibration diameter
in mm specifically for the calibration data
sets.
= -1 Default value
MD51772 $MNS_J_MEA_CAL_HEIGHT_FEEDAX[n] Pre-assignment of the calibration height
in mm, in the infeed axis, specific for the
calibration data sets.
= -99999 Default value
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 179
