Workpiece measurement
Sequence in milling technology:
1. The probe has been selected in the tool list as type 7xx (probe).
2. The probe has been inserted in the tool spindle.
3. The probe is activated in the actual NC channel.
Sequence in turning technology:
1.
Tool type 580 (3D probe, turning) is selected.
2. Tool is activated in the actual NC channel.
Tool measurement
To measure tools, an appropriate probe must be located in the machine space so that this can
be reliably and safely reached with a tool in the spindle.
The following tool types are supported with tool measurement:
● Milling technology: Tool types 1xx and 2xx
● Turning technology: Tool types 5xx, 1xx and 2xx
For the specified tool types, the tool lengths and the tool radii can be measured.
Channel-specific cycle setting data
Using the following channel-specific cycle setting data, you can adapt the workpiece and tool
measuring in the "Program" operating area to specific requirements. As a general rule, no
changes are required.
SD55613 $SCS_MEA_RESULT_DISPLAY Selects the screen display of the measur‐
ing result
= 0 No screen display of the measuring result (default value).
= 1 Screen display of the measuring result is displayed for 8 seconds.
= 3 The measuring cycle stops an internal machine data, the measuring result is statically dis‐
played on the screen!
Continue with NC start, the measuring result screen is deselected.
= 4 The measuring result is only displayed on the screen for cycle alarms 61303, 61304, 61305,
61306.
Continue with NC start, the measuring result display on the screen is deselected.
SD55614 $SCS_MEA_RESULT_MRD Setting of the program control of the measurement result dis‐
play MRD
= 0 Switch off the measurement result display
= 1 Switch on the measurement result display
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 187
