● Clamping system
● Logistics data
Requirements
● A spindle with DQI encoder: r0459, bit 14 = 1.
● Drive telegram 139 is configured for the spindle.
●
The spindle functionality for the machine axis is present when MD35000
$MA_SPIND_ASSIGN_TO_MACHAX > 0
The value corresponds to the spindle number.
References
For further information, please refer to the following documentation:
Basic Functions Function Manual: Spindles (S1)
Section "Spindle with SMI 24 (Weiss spindle)"
Data overview
The "S1 Spindle Diagnostics" window shows the following information:
Parameter Value
Operating hours
● Spindle under control
● Spindle under speed
h
Number of clamping cycles (tool change)
Definition of a clamping
cycle: Released clamping state [3] → Clamped clamping state
[7, 8 or 10] → Released clamping state [3].
Motor temperature °C
Clamping state (sensor 1) V
Piston free (sensor 4)
E.g. defined rotary angular position of the shaft (sensor 5) Yes/No
Maximum speed rpm
Procedure
1. Select the "Diagnostics" operating area.
2. Press the menu forward key.
3. Press the "Spindle diagostics" softkey to obtain a data overview.
The "S1 Spindle Diagnostics" window opens.
Spindle function
8.4 Spindle diagnostics
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 209
