direction holder angle" for this tool do not match, then a red cross is displayed for locked. The
yellow triangle for the conflict cannot be seen.
Entries Meaning
ShowSymbolActivePlace Marking of the magazine location at the machining position.
True - default setting applies for the "Turret" magazine type.
False - setting for all other magazine types.
ShowSymbolActiveMultiToolPlace Marking of the multitool location at the machining position. Is
only
displayed when the
multitool is located in the spindle or
the tool holder.
True - default setting.
ShowSymbolLoadPlace Selection of the magazine location at the loading position.
True - default setting applies for all magazine types (except
Turret is true).
False - setting for the "Turret" magazine type.
ShowSymbolChangeInSpindlePlace Marking of the magazine location at the change position.
True - default setting applies for all magazine types (except
Revolver is true).
False - setting for the "Turret" magazine type.
ShowSymbolActiveTool Marking of the active tool.
False - default setting.
ShowSymbolProgrammedTool Marking of the follow-on tool.
True - default setting.
ShowSymbolActiveDNo Marking of the active cutting edge.
False - default setting.
ShowSymbolActiveDNoInTool Marking of the active tool by marking the active cutting edge.
True - default setting for configuration without magazine
management.
False
- setting for
configuration with magazine management.
ShowSymbolAcitveDlNo Marking of the active DL number.
True - default setting.
ShowConflictPositionAndDirection Marking of a conflict; tool position and cutting direction do not
match.
True - default setting.
ShowConflictActiveToolWarning Marking of a conflict; turret magazine type and the active tool
are not at the the machining position.
True - default setting.
Example
<SETTINGS>
<ReactivateWithMagPos value="false" type="bool" />
<MagazineMoveMessage value="false" type="bool" />
<CreateNewToolDialog value="true" type="bool" />
<MagazineSelectionDialog value="false" type="bool" />
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 235
