Siemens SINUMERIK 828D Commissioning Manual

Identifier Parameter or property System variable
*)
ToolInMagInPlace Magazine number/Magazine location $A_TOOLMN /
$A_TOOL_MLN
ToolMonTCW Type of tool monitoring, tool life, workpiece
count
and wear. If
wear monitoring has not been
enabled via the machine data, this parameter is
handled like ToolMonTC.
$TC_TP9
ToolMonTC Type of tool monitoring, tool life and workpiece
count
$TC_TP9
ToolPlaceSpec Location type $TC_TP7
ToolPlaceSpecIdent Location type, if it is to be displayed as text. The
precondition
is that the text for the location type
was configured.
$TC_TP7
ToolSearch Tool search type for replacement tools $TC_TP10
ToolMyMag Owner magazine of the tool $A_MYMN
ToolMyPlace Owner magazine location of the tool $A_MYMLN
ToolSizeLeft Tool size left in half locations $TC_TP3
ToolSizeRight Tool size right in half locations $TC_TP4
ToolSizeUpper Tool size upper in half locations $TC_TP5
ToolSizeDown Tool size lower in half locations $TC_TP6
ToolOverSize Tool size as fixed setting - two half locations left,
two half locations right, one half location top,
one half location bottom
$TC_TP3 -
$TC_TP6
ToolState Tool status in the hexadecimal notation $TC_TP8
ToolStateActiv Tool status - tool active $TC_TP8, Bit0
ToolStateEnabled Tool status - tool released $TC_TP8, Bit1
ToolStateLocked Tool status - tool locked $TC_TP8, Bit2
ToolStateLockedRO Tool status - tool locked, only read access $TC_TP8, Bit2
ToolStateMeasured Tool status - tool measured $TC_TP8, Bit3
ToolStatePrewarn Tool status - tool has reached prewarning limit $TC_TP8, Bit4
ToolStatePrewarnRO Tool status - tool has reached prewarning limit,
only read access
$TC_TP8, Bit4
ToolStateInChange Tool status - tool is being changed $TC_TP8, Bit5
ToolStateFixed Tool status - tool fixed place coded $TC_TP8, Bit6
ToolStateUsed Tool status - tool was in use $TC_TP8, Bit7
ToolStateAutoReturn Tool status - automatic return $TC_TP8
ToolStateIgnoreLocked Tool status - do not observe locked $TC_TP8, Bit9
ToolStateMarkedToUnload Tool status - tool is marked to unload $TC_TP8, Bit10
ToolStateMarkedToLoad Tool status - tool is marked to load $TC_TP8, Bit11
ToolStatePermanent Tool status - tool is permanent $TC_TP8, Bit12
ToolState1To1Exchange Tool status - one to one replacement $TC_TP8, Bit14
ToolStateHandTool Tool status - manual tool $TC_TP8, Bit15
ToolProtAreaFile File name of the tool description which is re‐
quired to define the protection zone
$TC_TP_PROTA
ToolMaxVelo Maximum speed $TC_TP_MAX_
VELO
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 241

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
