OR:
The number of events
to be output and the type of logging can also be entered directly via the
user interface:
1. Press the "Alarm log" → "Settings >" softkey in the "Diagnostics" operating area.
As soon as changes are made to the default settings, the "slaesvcconf.xml" file is
automatically created in the /user/sinumerik/hmi/cfg directory.
2. Enter the mode of the permanent storage in the <DiskCare type="int" value="-1"/> identifier.
The following values are possible:
-1: The alarm protocol is not backed up (default setting).
0: Each alarm event initiates that the alarm log is immediately backed up.
>0: Time to backup the protocol in seconds:
When there is a change, the log is saved every n > 0 seconds.
3. You adapt the filter for the entry type in the <Filter> identifier.
Here the following applies:
– An alarm event is only entered in the log when it satisfies the filter criteria.
– When several filters are defined, these should be linked using the logical operators OR
or AND.
The settings become effective only after restarting the system.
Note
Number of events
Each incoming event and outgoing event of an alarm or message requires a separate entry,
even when they belong to the same alarm or message.
Acknowledgment results, which are
included in the alarm log, also require an entry even when
they cannot be recognized in the alarm log.
Examples
All alarms that fulfill the following conditions are logged:
CLEARINFO ≠ 15, therefore without part program messages:
<CONFIGURATION>
<Protocol>
<Filters>
<Siemens_Filter_01 type="QString" value="CLEARINFO NOT 15" />
</Filters>
</Protocol>
</CONFIGURATION>
"SEVERITY larger than 10" and "smaller than 500" :
<CONFIGURATION>
Operating software settings
3.6 Configuring PLC alarms
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 57
