Recording fundamentals: Signals (data)
Signals (data) specify what is to be recorded:
● NC variables (axis data, drive data, channel data, etc.)
● PLC data
Cyclic events
Interpolation clock cycle (IPO clock cycle)
PLC cycle OB1
Position control clock cycle (servo clock cycle)
Non-cyclic events
Starting a session
● Recording using a trigger
● Manually starting and stopping a trace
Analyzing the result
The following functions are available to analyze the result:
● Scaling characteristic graphs
●
Zooming characteristic graphs
● Defining a characteristic range using markers
Sequence
● Create a trace session file as follows:
– Select the variable and define its representation type.
– Set the graphics window, and the save mode
– Set the trigger property to define the start and end of recording
● Save the recording and its associated properties that have been set
● Analyze the result by making the settings for the display in order to view additional details
(e.g. zoom in, scroll, select section, etc.)
See also
Trace settings (Page 348)
Trace options (Page 350)
Saving the trace file (Page 361)
Evaluate a trace (Page 351)
Variables filter/search (Page 346)
Service and diagnostics
10.4 Trace
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 345
