Attributes Meaning
Pen Line type selection to display the characteristic graphs.
● No line
● Solid line
● Dashed line
●
Dash-dot line
● Dash-dot-dot line
● Dotted line
● Stepped line XY
● Stepped line YX
● "* line" (line made up of * symbols)
● + line
● X line
Qty. Defines whether the characteristic of the variables is displayed in the "Trace"
window. If the checkbox is not selected, then no characteristic graphs are dis‐
played.
Events Event selection which triggers that the signal is traced:
● Interpolation clock cycle (IPO clock cycle)
●
Interpolation cycle (IPO2)
● Position control clock cycle (servo clock cycle)
● PLC cycle OB1
●
Drive trace rate
● Start geometry axis/direction change
● Stop geometry axis
● Machine axis start / direction change
● Machine axis stop
● NC start (program runs)
● NC start (program ran)
● Start of the data recording
Service and diagnostics
10.4 Trace
SINUMERIK Operate
352 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
