Tag identifier Meaning
XML_PARSER Continued The parser also supplies variables so that the call-back functions can access the event
data.
startElementHandler:
Function parameters
tag_name - tag name
num - number of attributes found
System variables
$xmlAttribute String array that contains the 0-num attribute name range.
$xmlValue String array that contains the 0-num attribute value range.
Example:
<function_body name="startElementHandler" return="true"
parameter="tag_name, num">
<print text="attribute name %s"> $xmlAttribute[0]</print>
<print text="attribute value %s"> $xmlValue [0]</print>
</function_body>
endElementHandler:
Function parameters
tag_name - tag name
Example:
<function_body name="endElementHandler" parameter="tag_name">
<print text="name %s"> tag_name </print>
</function_body>
Generating user dialogs
1.6 XML identifier
Easy XML
40 Programming Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
