Tag identifier Meaning
FORM This tag contains the description of a user dialog.
Attributes:
● color
Background color of the dialog box (for color coding, see Chapter "Color coding
(Page 42)")
● name
Identifier of the form
● type
cycle -attribute specifies a cycle form
● xpos
X-position of the top left corner of the dialog box (optional)
● ypos
Y position of the top left corner (optional)
● width
Extension in the X direction (in pixels) (optional)
● height
Extension in the Y direction (in pixels) (optional)
FORM continued Dialog messages:
● INIT
● PAINT
● TIMER
● CLOSE
● FOCUS_IN
● INDEX_CHANGED
● EDIT_CHANGED
● KEY_EVENT
● MESSAGE
● MOUSE_EVENT
● RESIZE
Generating user dialogs
1.6 XML identifier
Easy XML
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 45

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
