Tag identifier Meaning
MESSAGE Dialog message
If the Send_message operation is executed in the script, then the parser processes the tag
message. Values P1 and P2 are provided in the variables $message_par1 and $mes‐
sage_par2 (see the "SEND_MESSAGE" tag).
Syntax:
<MESSAGE>
</MESSAGE>
Example:
<LET name="user_selection" />
<SOFTKEY POSITION="3">
<CAPTION>Set%nParameter</CAPTION>
<SEND_MESSAGE>1, 10</SEND_MESSAGE>
</SOFTKEY>
…
…
<FORM>
…
…
<MESSAGE>
<SWITCH>
<CONDITION>$message_par1</CONDITION>
<CASE value="1">
<OP> user_selection = $message_par2 </OP>
…
…
</CASE>
</SWITCH>
</MESSAGE>
…
…
</FORM>
Generating user dialogs
1.6 XML identifier
Easy XML
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 49

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
