This is then copied to the specified variable.

Tag identifier Description

NC_INSTRUCTION This tag is used to define the NC instruction to be generated.

All listed cycle parameters are automatically created as string variables of the

FORM and are available to the FORM.

Precondition: The FORMattribute type is set to the value CYCLE.

Attribute:

● refvar

If the tag

is assigned a reference variable, all parameters are pre-assigned with

the values from the NC block saved in the reference variables.

Syntax:

<NC_INSTRUCTION> NC instruction with placeholders </

NC_INSTRUCTION>

Example:

<let name="cyc_string" type="string"> Cycle100(0, 1000, 5)</

let>

...

<NC_INSTRUCTION refvar= "cyc_string" >Cycle100($p1, $p2,

$p3)</ NC_INSTRUCTION>

…

</FORM>

Generating user dialogs

1.7 Generating user menus

Easy XML

72 Programming Manual, 10/2015, 6FC5397-3DP40-5BA3
