Function name Description

Ncfunc PI-Service Continued Arguments:

● _N_CREATO

var1 - Tool number

● _N_DELETO

var1 - Tool number

●

_N_CREACE

var1 - Tool number

var2 - Cutting edge number

● _N_DELECE

var1 - Tool number

var2 - Cutting edge number

● _N_SETUFR

No arguments

● _N_SETUDT

var1- User data area to be activated

– 1 - Tool offset data

– 2 - Active basic frame

– 3 - Active adjustable frame

● _N_FINDBL

var1 - Search mode

– 2 - Search with contour calculation

– 4 - Search for the block end point

– 1 - Block search without calculation.

● _N_FINDAB

No arguments

Example:

● Creating a tool – tool number 3

<function name="ncfunc.pi_service">_T"_N_CREATO",

3</function>

● Delete cutting edge 1 of tool 5

<function name="ncfunc.pi_service">_T"_N_DELECE", 5, 1</func‐

tion>

Generating user dialogs

1.9 Predefined functions

Easy XML

Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 83
