Siemens SINUMERIK 828D

Function name Description
MMC continued Example of synchronous call:
Due to changes in the operate base system, the parameters are as
follows:
XML → CYCLES or POPUPDLG
XML_ON → PICTURE_ON
XML_OFF → PICTURE_OFF
NC instruction
MMC("EASYXML oder CYCLES”, XML_ON, mmc_cmd.xml,
cmd1,,,,,","S")
File: mmc_cmd.xml
<menu name = "cmd1">
<open_form name = "cmd1_form" />
<softkey_ok>
<close_form />
</softkey_ok>
</menu>
<form name = "cmd1_form" xpos ="12" ypos="100"
width="500" height="240">
<init>
</init>
<paint>
</paint>
</form>
Example of asynchronous call (acknowledgment not expected):
Due to changes in the operate base system, the parameters are as
follows:
XML → CYCLES or POPUPDLG
XML_ON → PICTURE_ON
XML_OFF → PICTURE_OFF
NC instruction
MMC("EASYXML oder CYCLES”, PICTURE_ON,
mmc_cmd.xml, cmd1,,,10,,","N")
File: mmc_cmd.xml <menu name = "cmd1">
<open_form name =
"cmd1_form" /> <softkey_ok>
<close_form /> </softkey_ok>
</menu>
<form name = "cmd1_form" xpos ="12" ypos="100"
width="500" height="240">
<init>
</init>
<paint>
</paint>
</form>
Generating user dialogs
1.9 Predefined functions
Easy XML
114 Programming Manual, 10/2015, 6FC5397-3DP40-5BA3
