Chapter 9 Color Corrector
346
Color Corrector Functions
a) See “Setting the wipe pattern replication (Multi)” (page 219).
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See “Setting the wipe pattern aspect ratio (Aspect ratio)” (page 218).
• When turning the [Angle] on in the <Rotation> group and slanting
the pattern
a) See “Angle” (page 216).
• When turning [Speed] on in the <Rotation> group and rotating the
pattern at a fixed rate
a) See “Speed” (page 216).
6
To invert the mask source, return to the Primary CCR menu and press
[Mask Invert], turning it on.
Note
The mask function is common to the primary color correction, secondary color
correction luminance processing, and spot color adjustment functions. For
example, if in primary color correction you set mask 1 to a box, then in
secondary color correction set mask 1 to a pattern, this also changes the setting
in primary color correction to the pattern.
2 V Multi Number of repetitions of pattern
vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Aspect aspect ratio
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of pattern
–100.00 to +100.00
a)
