27.5.77 HRTIM ADC trigger update register (HRTIM_ADCUR)
Address offset: 0x3FC
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. AD10USRC[2:0] Res. AD9USRC[2:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
Res. AD8USRC[2:0] Res. AD7USRC[2:0] Res. AD6USRC[2:0] Res. AD5USRC[2:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:23 Reserved, must be kept at reset value.
Bits 22:20 AD10USRC[2:0]: ADC trigger 10 update source
Refer to AD5USRC[2:0] description.
Bit 19 Reserved, must be kept at reset value.
Bits 18:16 AD9USRC[2:0]: ADC trigger 9 update source
Refer to AD5USRC[2:0] description.
Bit 15 Reserved, must be kept at reset value.
Bits 14:12 AD8USRC[2:0]: ADC trigger 8 update source
Refer to AD5USRC[2:0] description.
Bit 11 Reserved, must be kept at reset value.
Bits 10:8 AD7USRC[2:0]: ADC trigger 7 update source
Refer to AD5USRC[2:0] description.
Bit 7 Reserved, must be kept at reset value.
Bits 6:4 AD6USRC[2:0]: ADC trigger 6 update source
Refer to AD5USRC[2:0] description.
Bit 3 Reserved, must be kept at reset value.
Bits 2:0 AD5USRC[2:0]: ADC trigger 5 update source
These bits define the source which triggers the update of the ADC5TRG[4:0] bitfield in the
HRTIM_ADCER register (transfer from preload to active register). It only defines the source timer.
The precise condition is defined within the timer itself, with the BRSTDMA[1:0] bitfield in
HRTIM_MCR or the UPDGAT[3:0] bitfield in HRTIM_TIMxCR register.
000: Master timer
001: Timer A
010: Timer B
011: Timer C
100: Timer D
101: Timer E
110: Timer F
111: Reserved
