RM0440 Rev 4 339/2126
RM0440 Clock recovery system (CRS)
349
8 Clock recovery system (CRS)
8.1 Introduction
The clock recovery system (CRS) is an advanced digital controller acting on the internal
fine-granularity trimmable RC oscillator HSI48. The CRS provides powerful means for
oscillator output frequency evaluation, based on comparison with a selectable
synchronization signal. It is capable of doing automatic adjustment of oscillator trimming
based on the measured frequency error value, while keeping the possibility of a manual
trimming.
The CRS is ideally suited to provide a precise clock to the USB peripheral. In such case, the
synchronization signal can be derived from the start-of-frame (SOF) packet signalization on
the USB bus, which is sent by a USB host at 1 ms intervals.
The synchronization signal can also be derived from the LSE oscillator output or it can be
generated by user software.
8.2 CRS main features
• Selectable synchronization source with programmable prescaler and polarity:
– LSE oscillator output
– packet reception
• Possibility to generate synchronization pulses by software
• Automatic oscillator trimming capability with no need of CPU action
• Manual control option for faster start-up convergence
• 16-bit frequency error counter with automatic error value capture and reload
• Programmable limit for automatic frequency error value evaluation and status reporting
• Maskable interrupts/events:
– Expected synchronization (ESYNC)
– Synchronization OK (SYNCOK)
– Synchronization warning (SYNCWARN)
– Synchronization or trimming error (ERR)
8.3 CRS implementation
Table 52. CRS features
Feature CRS1
TRIM width 7 bits
