ST STM32G474

RM0440 Rev 4 901/2126
RM0440 High-resolution timer (HRTIM)
1083
Figure 229. Burst mode and delayed protection priorities (DIDL = 0)
The same priorities are applied when the delayed burst mode entry is enabled (DIDL bit
set), as shown on Figure 230 below.
MS32280V1
IDLE
Burst entry
Delayed protection
Entry (discarded, burst
has priority)
Burst exit
Delayed protection
exit (discarded, burst
has priority)
Burst entry
Delayed
protection
Entry
Burst exit (discarded,
delayed protection has
priority)
Delayed
protection
exit
RUN RUN
IDLERUN RUN
Output
State
Output
State
