Flexible static memory controller (FSMC) RM0440
534/2126 RM0440 Rev 4
Table 137. FMC_BCRx bitfields (mode C)
Bit number Bit name Value to set
31:24 Reserved 0x000
23:22 NBLSET[1:0] Don’t care
20 CCLKEN As needed
19 CBURSTRW 0x0 (no effect in Asynchronous mode)
18:16 CPSIZE 0x0 (no effect in Asynchronous mode)
15 ASYNCWAIT Set to 1 if the memory supports this feature. Otherwise keep at 0.
14 EXTMOD 0x1
13 WAITEN 0x0 (no effect in Asynchronous mode)
12 WREN As needed
11 WAITCFG Don’t care
10 Reserved 0x0
9 WAITPOL Meaningful only if bit 15 is 1
8 BURSTEN 0x0
7 Reserved 0x1
6 FACCEN 0x1
5:4 MWID As needed
3:2 MTYP 0x02 (NOR Flash memory)
1 MUXEN 0x0
0 MBKEN 0x1
Table 138. FMC_BTRx bitfields (mode C)
Bit number Bit name Value to set
31:30 DATAHLD
Duration of the data hold phase (DATAHLD HCLK cycles for read
accesses).
29:28 ACCMOD 0x2
27:24 DATLAT 0x0
23:20 CLKDIV 0x0
19:16 BUSTURN Time between NEx high to NEx low (BUSTURN HCLK).
15:8 DATAST
Duration of the second access phase (DATAST HCLK cycles) for
read accesses.
7:4 ADDHLD Don’t care
3:0 ADDSET
Duration of the first access phase (ADDSET HCLK cycles) for read
accesses. Minimum value for ADDSET is 0.
