RM0440 Rev 4 629/2126

RM0440 Analog-to-digital converters (ADC)

724

adc_jext_trg9 TIM8_TRGO Internal signal from on-chip timers 01001

adc_jext_trg10 TIM8_TRGO2 Internal signal from on-chip timers 01010

adc_jext_trg11 TIM3_CC3 Internal signal from on-chip timers 01011

adc_jext_trg12 TIM3_TRGO Internal signal from on-chip timers 01100

adc_jext_trg13 TIM3_CC1 Internal signal from on-chip timers 01101

adc_jext_trg14 TIM6_TRGO Internal signal from on-chip timers 01110

adc_jext_trg15 TIM15_TRGO Internal signal from on-chip timers 01111

adc_jext_trg16 TIM20_TRGO Internal signal from on-chip timers 10000

adc_jext_trg17 TIM20_TRGO2 Internal signal from on-chip timers 10001

adc_jext_trg18 TIM20_CC4 Internal signal from on-chip timers 10010

adc_jext_trg19 hrtim_adc_trg2 Internal signal from on-chip timers 10011

adc_jext_trg20 hrtim_adc_trg4 Internal signal from on-chip timers 10100

adc_jext_trg21 hrtim_adc_trg5 Internal signal from on-chip timers 10101

adc_jext_trg22 hrtim_adc_trg6 Internal signal from on-chip timers 10110

adc_jext_trg23 hrtim_adc_trg7 Internal signal from on-chip timers 10111

adc_jext_trg24 hrtim_adc_trg8 Internal signal from on-chip timers 11000

adc_jext_trg25 hrtim_adc_trg9 Internal signal from on-chip timers 11001

adc_jext_trg26 hrtim_adc_trg10 Internal signal from on-chip timers 11010

adc_jext_trg27 TIM16_CC1 Internal signal from on-chip timers 11011

adc_jext_trg28 reserved - 11100

adc_jext_trg29 LPTIMOUT Internal signal from on-chip timers 11101

adc_jext_trg30 TIM7_TRGO Internal signal from on-chip timers 11110

adc_jext_trg31 reserved - 11111

Table 164. ADC1/2 - External trigger for injected channels (continued)

Name Source Type JEXTSEL[4:0]

Table 165. ADC3/4/5 - External triggers for regular channels

Name Source Type EXTSEL[4:0]

adc_ext_trg0 TIM3_CC1 Internal signal from on-chip timers 00000

adc_ext_trg1 TIM2_CC3 Internal signal from on-chip timers 00001

adc_ext_trg2 TIM1_CC3 Internal signal from on-chip timers 00010

adc_ext_trg3 TIM8_CC1 Internal signal from on-chip timers 00011

adc_ext_trg4 TIM3_TRGO Internal signal from on-chip timers 00100

adc_ext_trg5 EXTI line 2 External pin 00101

adc_ext_trg6 TIM4_CC1 Internal signal from on-chip timers 00110

adc_ext_trg7 TIM8_TRGO Internal signal from on-chip timers 00111
