Embedded Flash memory (FLASH) for category 2 devices RM0440
218/2126 RM0440 Rev 4
5.7.6 Flash control register (FLASH_CR)
Address offset: 0x14
Reset value: 0xC000 0000
Access: no wait state when no Flash memory operation is on going, word, half-word and
byte access
Bit 6 SIZERR: Size error
Set by hardware when the size of the access is a byte or half-word during a
program or a fast program sequence. Only double word programming is allowed
(consequently: word access).
Cleared by writing 1.
Bit 5 PGAERR: Programming alignment error
Set by hardware when the data to program cannot be contained in the same 64-
bit Flash memory row in case of standard programming, or if there is a change of
page during fast programming.
Cleared by writing 1.
Bit 4 WRPERR: Write protection error
Set by hardware when an address to be erased/programmed belongs to a write-
protected part (by WRP, PCROP or RDP level 1) of the Flash memory.
Cleared by writing 1.
Bit 3 PROGERR: Programming error
Set by hardware when a double-word address to be programmed contains a
value different from '0xFFFF FFFF' before programming, except if the data to
write is '0x0000 0000'.
Cleared by writing 1.
Bit 2 Reserved, must be kept at reset value.
Bit 1 OPERR: Operation error
Set by hardware when a Flash memory operation (program / erase) completes
unsuccessfully.
This bit is set only if error interrupts are enabled (ERRIE = 1).
Cleared by writing ‘1’.
Bit 0 EOP: End of operation
Set by hardware when one or more Flash memory operation (programming /
erase) has been completed successfully.
This bit is set only if the end of operation interrupts are enabled (EOPIE = 1).
Cleared by writing 1.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
LOCK
OPT
LOCK
Res.
SEC_
PROT1
OBL_
LAUNCH
RD
ERRIE
ERR
IE
EOP
IE
Res. Res. Res. Res. Res. FSTPG
OPT
STRT
STRT
rs rs rs rc_w1 rw rw rw rw rs rs
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. Res. Res. PNB[6:0] MER1 PER PG
rw rw rw rw rw rw rw rw rw rw
