RM0440 Rev 4 863/2126
RM0440 High-resolution timer (HRTIM)
1083
This mode is enabled by writing HALF bit to 1 in the HRTIM_TIMxCR register. When the
HRTIM_PERxR register is written, it causes an automatic update of the compare 1 value
with HRTIM_PERxR/2 value.
The output on which a square wave is generated must be programmed to have one
transition on CMP1 event, and one transition on the period event, as follows:
– HRTIM_SETxyR = 0x0000 0008, HRTIM_RSTxyR = 0x0000 0004, or
– HRTIM_SETxyR = 0x0000 0004, HRTIM_RSTxyR = 0x0000 0008
The HALF mode overrides the content of the HRTIM_CMP1xR register. The access to the
HRTIM_PERxR register only causes compare 1 internal register to be updated. The user-
accessible HRTIM_CMP1xR register is not updated with the HRTIM_PERxR / 2 value.
When the preload is enabled (PREEN = 1, MUDIS, TxUDIS), compare 1 active register is
refreshed on the update event. If the preload is disabled (PREEN= 0), compare 1 active
register is updated as soon as HRTIM_PERxR is written.
The period must be greater than or equal to 6 periods of the f
HRTIM
clock (0xC0 if
CKPSC[2:0] = 0, 0x60 if CKPSC[2:0] = 1, 0x30 if CKPSC[2:0] = 2,...) when the HALF mode
is enabled.
Interleaved mode
This mode complements the Half mode and helps the implementation of interleaved
topologies.
It allows to re-compute automatically the content of compare registers when the
HRTIM_PERxR value is updated.
The selection is done using the HALF bit and the IL[1:0] bits in HRTIM_MCR and
HRTIM_TIMxCR registers, as shown on the Table 217 below.
Table 218 gives the compare values for the 3 available modes. The content of the compare
registers is overridden. The corresponding compare events can be used to trigger an output
set / reset or to reset a slave timer.
Table 217. Interleaved mode selection
HALF bit
INTLVD
[1:0] bits
Mode
0 00 Disabled
0 01 Triple interleaved (120°)
0 10 Quad interleaved (90°)
0 11 Reserved
1 xx Dual interleaved (180°)
