ST STM32G474 User Manual

Digital-to-analog converter (DAC) RM0440
732/2126 RM0440 Rev 4
dac_inc_chx_trg3 (x = 1, 2) TIM15_TRGO
Internal signal from on-chip
timers
dac_inc_chx_trg4 (x = 1, 2) TIM2_TRGO
Internal signal from on-chip
timers
dac_inc_chx_trg5 (x = 1, 2) TIM4_TRGO
Internal signal from on-chip
timers
dac_inc_chx_trg6 (x = 1, 2) EXTI10 External pin
dac_inc_chx_trg7 (x = 1, 2) TIM6_TRGO
Internal signal from on-chip
timers
dac_inc_chx_trg8 (x = 1, 2) TIM3_TRGO
Internal signal from on-chip
timers
dac_inc_chx_trg9 (x = 1, 2) hrtim_dac_step_trg1
Internal signal from on-chip
timers
dac_inc_chx_trg10 (x = 1, 2) hrtim_dac_step_trg2
Internal signal from on-chip
timers
dac_inc_chx_trg11 (x = 1, 2) hrtim_dac_step_trg3
Internal signal from on-chip
timers
dac_inc_chx_trg12 (x = 1, 2) hrtim_dac_step_trg4
Internal signal from on-chip
timers
dac_inc_chx_trg13 (x = 1, 2) hrtim_dac_step_trg5
Internal signal from on-chip
timers
dac_inc_chx_trg14 (x = 1, 2) hrtim_dac_step_trg6
Internal signal from on-chip
timers
Table 185. DAC4 interconnection
Signal name Source Source type
dac_hold_ck
ck_lsi or ck_lse (selected in
RCC)
LSI or LSE clock selected in the
RCC
dac_chx_trg1 (x = 1, 2) TIM8_TRGO
Internal signal from on-chip
timers
dac_chx_trg2 (x = 1, 2) TIM7_TRGO
Internal signal from on-chip
timers
dac_chx_trg3 (x = 1, 2) TIM15_TRGO
Internal signal from on-chip
timers
dac_chx_trg4 (x = 1, 2) TIM2_TRGO
Internal signal from on-chip
timers
dac_chx_trg5 (x = 1, 2) TIM4_TRGO
Internal signal from on-chip
timers
dac_chx_trg6 (x = 1, 2) EXTI9 External pin
dac_chx_trg7 (x = 1, 2) TIM6_TRGO
Internal signal from on-chip
timers
Table 184. DAC3 interconnection (continued)
Signal name Source Source type
