35.5 RTC interrupts
The interrupt channel is set in the masked interrupt status register. The interrupt output is
also activated.
35.6 RTC registers
Refer to Section 1.2 on page 72 of the reference manual for a list of abbreviations used in
register descriptions.
The peripheral registers can be accessed by words (32-bit).
35.6.1 RTC time register (RTC_TR)
The RTC_TR is the calendar time shadow register. This register must be written in
initialization mode only. Refer to Calendar initialization and configuration on page 1547 and
Reading the calendar on page 1549.
This register is write protected. The write access procedure is described in RTC register
write protection on page 1547.
Address offset: 0x00
Backup domain reset value: 0x0000 0000
System reset value: 0x0000 0000 (when BYPSHAD = 0, not affected when BYPSHAD = 1)
Table 335. Interrupt requests
Interrupt acronym
Interrupt
event
Event
flag
(1)
Enable
control bit
(2)
Interrupt
clear
method
Exit from
Sleep
mode
Exit from
Stop and
Standby
mode
Exit from
Shutdown
mode
RTC
Alarm A ALRAF ALRAIE
write 1 in
CALRAF
Yes Yes
(3)
Yes
(4)
Alarm B ALRBF ALRBIE
write 1 in
CALRBF
Yes Yes
(3)
Yes
(4)
Timestamp TSF TSIE
write 1 in
CTSF
Yes Yes
(3)
Yes
(4)
Wakeup timer
interrupt
WUTF WUTIE
write 1 in
CWUTF
Yes Yes
(3)
Yes
(4)
1. The event flags are in the RTC_SR register.
2. The interrupt masked flags (resulting from event flags AND enable control bits) are in the RTC_MISR register.
3. Wakeup from Stop and Standby modes is possible only when the RTC clock source is LSE or LSI.
4. Wakeup from Shutdown modes is possible only when the RTC clock source is LSE.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. PM HT[1:0] HU[3:0]
rw rw rw rw rw rw rw
1514131211109876543210
Res. MNT[2:0] MNU[3:0] Res. ST[2:0] SU[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
