RM0440 Rev 4 857/2126
RM0440 High-resolution timer (HRTIM)
1083
Figure 185. Continuous timer operation
Figure 186. Single-shot timer operation
MS32259V1
Reset
Counter
PER
Continuous mode (CONT = 1, RETRIG = X)
Enable
MS32260V1
Reset*
Counter
PER
Reset*
Counter
PER
Single-shot mode, non-retriggerable (CONT = 0, RETRIG = 0)
Single-shot mode, retriggerable (CONT = 0, RETRIG = 1)
Enable
Enable
* Legend: Reset active Reset ignored
PER event
PER event PER event
PER event
