VM15 User Manual SpO2 Monitoring
123
Display of SpO2 APG
SpO2 APG Measuring Screen.
Figure 19-5. Display - SPO2 APG
Description of APG
The Pulse wave made recorded to the wave of chest wall and large blood vessel by heart rate.
We can presume the age of blood vessel by elasticity of blood vessel with APG.
APG measured value: It is expressed to 1~8 and the age range of blood vessel too. The more
measured value is high, it means that the age of blood vessel is old.
Description of SpO
2
functions
When you select the SpO2 Numeric Area in the SpO2 menu appears.
All functions are available at SpO2 menu.
Press X button and SpO2 menu shall be disappeared from the screen.
The below picture shows SpO2 menu.
Figure 19-6 Displays - SpO2 Menu – STD1
Figure 19-7 Displays - SpO2 Menu – STD2
