VOTEM VM15 - IBP Measurement Trouble; CO2 Measurement Trouble; Qcon Measurement Trouble; TEMP Measurement Trouble

VM15 User Manual Troubleshooting
230
IBP Measurement Trouble
Table 34-7. IBP Measurement Issues
Symptoms
Description
Unstable BP Measurement
1. Separate the tube and remove the air bubble and make the tubing length
shorter.
Abnormal Waves
1. Do not touch or move the IBP Sensor.
CO2 Measurement Trouble
Table 34-8. CO2 Measurement Issues
Symptoms
Description
FILTERLINE
NOT CONNECTION
Connect Filter line.
EtCO2 FiCO2 is in Black color
Contact the regional distributor.
No Wave and value of EtCO2
Check the sampling line and filter. Clean them. Change if necessary. Disconnect
the filter line and connect again.
qCON Measurement Trouble
Table 34-9. qCON Measurement Issues
Symptoms
Description
Measurement does not start
Check sensor attachment status and sensor position to the patient
Check the contact between the skin and the sensor
Check all cable connections
qCON signal is weak.
Check the contact between the skin and the sensor
Check the sensor
Make sure the product is not close to other electrical emission equipment.
TEMP Measurement Trouble
Table 34-10. TEMP Measurement Issues
Symptoms
Description
Temperature is not measured
Check that the probe adapter is properly connected to the acquisition module.
Check that the probe is properly connected to the probe adapter.
Make sure you are using the correct probe for the monitored anatomical
location.
Use a probe that is compatible with your system.
If the sensor is damaged, try using a good probe.
Make sure the acquisition module is properly connected to the monitor.
Make sure there are no two identical measurement modules in the system.
