VM15 User Manual SpO2
Monitoring
124
SPEED Function
To control the speed of SpO2 wave.
Four steps: 6.25, 12.5, 25, 50mm/sec
GAIN Function
To control the size of SpO2 wave.
Six steps: x0.25, x0.5, x1, x2, x3, x4
AVERAGING Function
To control the calculation of the SpO2 mean.
Nine Steps: 2,3,4,5,6,7,8,9,10
APG Function
To control the APG (ON / OFF)
SpO2 ALARM Function
Alarm setting to be done for each Alarm
⚫ HIGH alarm set: 0~100, OFF
⚫ LOW alarm set: OFF, 0~100
⚫ TYPE alarm set: HIGH, MEDIUM, LOW, OFF.
PR ALARM Function
Alarm setting to be done for each Alarm
⚫ HIGH alarm set: 30~300, OFF
⚫ LOW alarm set: OFF, 30~300
⚫ TYPE alarm set: HIGH, MEDIUM, LOW, OFF.
SETUP TM
NOTE : The following applies only to STD1.
SpO2 can set SPEED 6.25, 12.5, 25, 50mm/sec.
SpO2 can set GAIN x0.25, x0.5, x1, x2, x3, x4.
