VM15 User Manual NIBP Monitoring
146
General
Oscillometric method is used for NIBP function.
Calculate the measuring value during the process of compression and decompression done
by LPC (Linear Pressure Controlled) NIBP module.
Setup Connection
Preparation of the Patient
Measure the NIBP at arms and legs of the patient.
Use the proper size of the cuffs.
How to connect accessory to equipment
Connect the one end of the NIBP Hose into the patient monitor. Connect the other end of
NIBP Hose into the NIBP Cuff.
Figure 21-1. NIBP Cable Connection – STD1
Figure 21-2. NIBP Cable Connection – STD2
How to connect accessory to patient
How to connect NIBP Cuff
I. NIBP Hose should be locate inside to arm-direction because NIBP value can be
changed according to the location of Cuff.
II. Refer to Fiqure 20-2. for Cuff installation.
