VM15 User Manual Specification
245
EtCO2 (End-Tidal CO2) - Optional
⚫ Mainstream (EtCO2)
◼ Initialization Time
◆ Capnogram, displayed in less than 15 seconds (at 25℃)
◆ Full specifications within 2 minutes
◼ Respiration Rate Range: 0 ~ 150 BPM (Breaths Per Minute)
◼ Respiration Rate Accuracy: ± 1 breath
◼ CO2 Measurement Range
◆ 0 ~ 150 mmHg
◆ 0 ~ 19.7%
◆ 0 ~ 20 kPa (at 760 mmHg)
◆ Barometric Pressure supplied by host
◼ Rise Time
◆ Less than 60 ms - Adult Reusable or Single-Patient-Use Airway Adapter
◆ Less than 60 ms - Infant Reusable or Single-Patient-Use Airway Adapter
◼ CO2 Resolution
◆ 0 ~ 69 mmHg → 0.1 mmHg
◆ 70 ~ 150 mmHg → 0.25 mmHg
◼ CO2 Accuracy
◆ 0 ~ 40 mmHg → ± 2 mmHg
◆ 41 ~ 70 mmHg → ± 5% of reading
◆ 71 ~ 100 mmHg → ± 8% of reading
◆ 01 ~ 150 mmHg → ± 10% of reading
◼ CO2 Stability
◆ Short Term Drift: Drift over four hours shall not exceed 0.8 mmHg max
◆ Long Term Drift: Accuracy specification will be maintained over a 120-hour period
◼ Calibration
◆ No routine user calibration required.
◆ An airway adapter zero is required when changing to a different style of airway
adapter.
◼ Temperature and Humidity
◆ Operating Environment: 0 ~ 45℃, 10 ~ 90% RH, non-condensing
◆ Storage Environment: -40 ~ 70℃, <90% RH, non-condensing
◼ Waterproof: IPX4, Splash-proof (sensor head only)
◼ Required Voltage: +5.0 VDC, 1.125 W Typical (Max 1.5 W)
◼ Power Rating
◆ Rated input: 1.1 Watts typical. Steady State
◆ Up to 1.5 Watts maximum on power up (warm up)
