VM15 User Manual Explanation of ICO (Option)
163
Description of IBP functions
When you select the IBP Numeric Area in the IBP menu appears.
All functions are available at IBP menu.
Press X button and IBP menu shall be disappeared from the screen.
The below picture show IBP menu.
Figure 23-10. Displays - IBP Menu
SPEED Function
To control the speed of IBP wave.
IBP can set SPEED 6.25, 12.5, 25, 50mm/sec.
SCALE Function
OPTIMUM : Wave Gain Auto Scale
FIXED : Wave Gain 0~200mmhg FIXED Scale.
LABEL Function
Four kinds of LABEL : ABP, CVP, LAP, PAP.
Table 23-2. LABEL Table by measuring part
