VOTEM VM15 - How to Connect to ICO

VM15 User Manual Explanation of ICO (Option)
166
How to connect to ICO
CAUTION: Designed to fit catheter made by Edward company.
CAUTION: All invasive procedures pose a risk to the patient.
Use aseptic technique.
Misuse of the catheter can result in vascular perforation.
Follow the catheter manufacturer's instructions
CAUTION: During electrosurgery, errors may occur in the results of cardiac
output measurements.
- The ICO connection cable connects to the VM15's left side ICO terminal
- Connect the Thermistor connector of the Swan-Ganz Standard Thermodilution
Pulmonary Artery Catheter to the other end of the ICO connection cable connecting the
product.
(Please refer to the picture below)
Figure 24-1. Swan-Ganz Standard Thermodilution Pulmonary Artery Catheter
Note. For details on how to use the catheter, follow the catheter manufacturer's
instructions.
Note. Refer to "IBP Monitoring" for how to use IBP measurement.
